工地施工圍擋搭建安裝時，經費有限但又想選擇既美觀又堅固實用的施工圍擋，該怎么選擇呢？選哪種合適呢？

When building and installing the construction fence on the construction site, the cost is limited, but you want to choose a beautiful, solid and practical construction fence, how to choose? Which one is suitable?

復合夾芯圍擋

Composite sandwich enclosure

復合夾芯圍擋由上下兩層金屬面板和中層高分子隔熱內芯壓制而成，吸音防震效果好，耐腐蝕耐高溫，安裝簡單快捷牢固，抗風阻系數高，是市政施工臨時圍蔽的佳選擇。

The composite sandwich enclosure is pressed by the upper and lower metal panels and the middle polymer insulation inner core. It has good sound absorption and shock resistance, corrosion resistance and high temperature resistance, simple, fast and firm installation, and high wind resistance coefficient. It is a good choice for temporary enclosure of municipal construction.

夾芯板板面：H1800mm*L2900mm

Sandwich panel surface: h1800mm*l2900mm

夾心材料及厚度：泡沫材料，49mm厚

Sandwich material and thickness: foam material, 49mm thick

立柱底板（法蘭盤）：120mm*180mm

Column base plate (flange): 120mm*180mm

橫梁：鍍鋅壓槽1.0厚，C型槽。

Beam: galvanized pressing groove 1.0 thick, C-shaped groove.

黃黑檔板：3000mm*200mm*1.3mm

Yellow and black baffle: 3000mm*200mm*1.3mm

柱帽：100mm*100mm*50mm

Column cap: 100mm*100mm*50mm

膨脹螺絲：10mm*100mm（立柱底板用）

Expansion screw: 10mm*100mm (for column base plate)

膨脹螺絲：8mm*80mm（斜撐專用）

Expansion screw: 8mm*80mm (special for diagonal bracing)

彩鋼圍擋

Color steel enclosure

彩鋼圍擋是經過機器壓型、噴漆、折彎等加工后的一種工地維護及與外界隔離的一種型材，適用于建筑工地，公路養護，施工現場的一種輕型與外界隔離板材，其防火，防水，防潮重量輕等特點被廣泛應用。

Color steel fence is a kind of profile for site maintenance and isolation from the outside after machine molding, painting, bending and other processing. It is suitable for construction sites, highway maintenance, and a kind of light-weight isolation plate at construction sites. Its fire prevention, waterproof, moisture-proof, light weight and other characteristics are widely used.

立柱：80mm方*0.8mm厚

Column: 80mm square *0.8mm thick

板：0.27mm厚

Plate: 0.27mm thick

背撐25方管0.7厚

Back brace 25 square tube 0.7 thick

斜支撐：25方管管*0.6mm厚

Inclined support: 25 square tubes *0.6mm thick

黑黃警示帶：0.25mm厚

Black and yellow warning tape: 0.25mm thick

長度：3.14米

Length: 3.14m

高度：為1.8米，2米，2.5米

Height: 1.8m, 2m, 2.5m

pvc圍擋

PVC enclosure

pvc圍擋由磚砌成的基座、立柱、上下橫梁、PVC板組成，產品結構和接點用高強度專用螺釘固定與拼裝，基座底部與地面用螺栓固定，其穩定性、美觀性好，不生銹、耐腐蝕，無需刷漆，大大降低了日常維護的工本費用，避免了對環境的污染。

The PVC enclosure is composed of a brick base, columns, upper and lower beams, and PVC plates. The product structure and joints are fixed and assembled with high-strength special screws, and the bottom of the base is fixed with bolts on the ground. It has good stability and aesthetics, is not rusty, corrosion-resistant, and does not need painting, which greatly reduces the cost of daily maintenance and avoids environmental pollution.

圍擋規格：2000/2500mm*3000mm尺寸或顏色可定制

Enclosure specification: 2000/2500mm*3000mm size or color can be customized

立柱規格：120*120PVC立管，內襯為：100*100*1.0鋼管

Column specification: 120*120pvc riser, lining: 100*100*1.0 steel pipe

上下橫管規格：80*50PVC管，下橫管內襯為：40*40*0.8鋼管

Specification of upper and lower horizontal pipes: 80*50pvc pipe, inner lining of lower horizontal pipe: 40*40*0.8 steel pipe

板面由10塊雙層中空高強度PVC板組成，扣板厚度為22mm，顏色是藍色立柱與地面采用膨脹螺絲固定。

The board surface is composed of 10 double-layer hollow high-strength PVC boards, the thickness of the gusset plate is 22mm, the color is blue, and the column and the ground are fixed with expansion screws.

施工圍擋廠家講解圍擋選擇哪種很實用的相關內容便是這樣了，如果您對其有什么不了解的，就來我們網站http://www.yibao68.com咨詢吧。

The construction enclosure manufacturer explains which kind of enclosure is very practical. If you don't know anything about it, come to our website http://www.yibao68.com Consult.
